MIL-G-85742/3(AS)
19 December 1986
MILITARY SPECIFICATION SHEET
GUIDANCE CONTROL SECTION, GUIDED MISSILE
POWER SUPPLY ASSEMBLY
This specification is approved for use within the Naval Air Systems Command,
Department of the Navy, and is available for use by all departments and
agencies of the Department of Defense.
The requirements for acquiring the power supply assembly described herein
shall consist of this specification and the latest issue of MIL-G-85742.
1.
SCOPE
1.1 Scope. This specification sheet establishes the performance and
test requirements for the power supply assembly used in the Guidance
Control Section of the SIDEARM Missile.
2.
APPLICABLE DOCUMENTS.
2.1 Government drawings. The following drawings, in addition to the
applicable documents listed in MIL-G-85742, are applicable to this specifi-
cation sheet.
Naval Air Systems Command
(Code Ident 30003)
1466AS1302
Power Supply Assembly.
3.
REQUIRMENTS
3.1 Item description. The power supply assembly is a part of the
receiver section. It provides regulated ±27 volts (V), ±15 V, and +5 V
supplies as well as a +15 V supply with a floating ground for the yttrium
iron garnet (YIG) oscillator in the receiver subassembly. The power supply
also provides unregulated ± 35 V supplies and an 86 volts root-mean-square
(Vrms) supply to the seeker section. The gyro drive board of the power
supply generates a three-phase voltage to drive the head gyro in the seeker
section.
Approved for public release; distribution is
DISTRIBUTION STATEMENT A.
unlimited.
1 of 3
AMSC N/A
