MIL-G-85742/4(AS)
19 December 1986
MILITARY SPECIFICATION SKEET
GUIDANCE CONTROL SECTION, GUIDED MISSILE
G-BIAS/NAV GAIN ASSEMBLY
This specification is approved for use with the Naval Air Systems Command.,
Department of the Navy, and is available for use by all departments and
agencies of the Department of defense.
The requirements for acquiring the G-kiss/Nav Gain described herein shall
consist of this specification and the latest issue of MIL-G-85742.
1.
SCOPE
l.1 Scope. This specification sheet establishes the performance and
test requirements for the G-Bias/Nav Gain Assembly used in the Guidance
Control Section of the SIDEARM Missile.
2.
APPLICABLE DOCUMENTS.
2.1 Government drawings. The following drawings, in addition to the
applicable documents listed in MIL-G-85742, are applicable to this specifi-
cation sheet.
Naval Air Systems Command
(Code Ident 30003)
1466As1324
G-Bias/Nav Gain Assembly
1466AS1326
PW3 Assembly G-Bias
3.
REQUIREMENTS
3.1 Item description. The G-Bias/Nav Gain (GB/NG) assembly is a part of
the receiver section. provides steering data to the magnetic amplifier
(Magamp) during flight in order to guide the missile to its target. The
G-Bias function senses the gravity vector direction and outputs signals
which are translated into fin torque used to counteract the force of gra-
vity. These signals are combined on the Nav Gain board with steering data
from the seeker section. A navigation gain function is superimposed on the
steering data in order to vary the magnitude of the fin torque as a func-
tion of time.
DISTRIBUTION STATEMENT A.
Approved for public release; distribution is
unlimited.
AMSC N/A
1 of 8
